Features | Applications |
Mini Size Low Excess Loss High Isolation High Stability And Reliability | Erbium Doped Fiber Amplifiers (EDFA) Testing Instruments Wdm Systems |
Confguration | Unit | 1×2 | |
Type |
| MiniFusedWDM(WDM) | |
OperatingWavelength | nm | 980/1550 | |
OperatingBandwidth | nm | 960-990/1526-1570 | |
InsertionLoss | dB | ≤0.20 | |
Isolation | dB | ≥19.00 | |
PDL | dB | ≤0.08 | |
ReturnLoss | dB | ≥50.00 | |
Directivity | dB | ≥55.00 | |
OperatingTemperature | Deg. | -5-75 | |
StorageTemperature | Deg. | -40-85 | |
FiberLength | m | 1.00±0.10 | |
FiberType |
| HI1060fex or OFS-20 | |
FiberDiameter | um | 250 | 250or900 |
Package | mm | 2.0×20,2.4×25,3×30 | 2.4×35,3×35 |
WDM | X | X | X | X | X | X |
WDM: | Operating | Package | FiberDiameter | Package | FiberType | Connector |
MiniFused | Wavelength | 1:2×20 | 1:2.0×20 | 1:ofs-16 | 1:none | |
WDM | 1:980/1550 | 2:2.4×25 | 1:250um | 2:2.4×25 | 2:ofs-20 | 2:LC/UPC |
` | 5:other | 3:3×30 | 2:900um | 3:3.0×30 | 3:HI1060 | 3:LC/APC |
| 4:2.4×35 | 3:other | 4:2.4×35 | 4:HI1060Flex | 4:SC/UPC | |
| 5:3×35 |
| 5:3.0×35 | 5:other | 5:SC/APC | |
| 6:other |
| 6:other |
| 6:FC/UPC | |
|
|
|
|
| 7:FC/APC | |
|
|
|
|
| 8:other |
